EOE network audio system includes EOE632 Main Unit, E5 Network Active Speaker and EP2 Power Supply Adapter. It adopts new technology to transmit power supply and 48K Hz / 24Bit digital audio signal simultaneously in one CAT~5/6 cable with transmitting distance up to 100 meter for every speaker. The main unit in standard 19’rack with 1.5U height uses universal power supply of AC100~240V 50/60Hz, includes 4 individual isolated power supply outputs to ensure zone with strong enough power supply and safety. E5 speaker has built~in special decoder, Class D amplifier, high fidelity 5’woofer and 1/2’tweeter with clear and low distortion sound. The system features smart size, easy to suspension, clear and precise sound, long distance transmission, no interference and low loss, suitable for applications requiring high sound quality such as conference room, school, hall of worship, exhibition hall.
Features
1) The Main Unit support one inputs of AES/EBU, optical fiber and stereo analogue signal.
2) 8 volume controls separately for 8 zones on the Main Unit able to conveniently control every zone volume, with 4 separate power switch, each for every 4 speakers.
3) The Main Unit has 16 channels in 8 groups speaker outputs and 8 channels digital signal outputs.
4) Only one CAT-5/6 net cable and RJ45 connectors can connect the Main Unit and the speaker, easy to install.
5) EP2 Power Supply Adapter is available to power E5 speakers extended from 8 channels digital output of the EOE632 Main Unit in case more power and signal outputs are needed than that the Main unit has.
6) E5 speaker has one input and one digital link out, able to link next E5 speaker through the EP2 Power Supply Adapter.
7) Four E5 speakers can be connected in series through EP2 Power supply adapter. One EOE632 Main Unit with 4 x (16ch + 8ch) output can connect 96 E5 speakers in theory, the max length is 100 meter net cable between the Main Unit and the E5 speaker.
8）The speaker can switch among L, L+R, R channels and can set two speakers in stereo output.
