OK6 Introduction
? Special middle vocal sound channel, equally output the mixing MIC/MONO/STEREO signal
? 3CH MIC input, 2CH Stereo input
? The maximum volume of MIC and Music signal can be set
? The Hi-, mid- and Low frequency of MIC is adjustable.
? With low-cut function.
? Built-in electronic crossover circuit, with separate sub low frequency output, the frequency point and volume can be adjusted independently.
? Vocal sound rendering technology adopted.
? Easy operation, high efficiency, good performance-to-Price Ratio
OK6 Specifications
Frequency Response (music): 20Hz-20KHz
S/N (music): 70dB
Input Sensitivity (music OUT 4V): 250mV
(microphone OUT 4V): 10mV
Max Output THD≤0.5%: 5V
Music BASS: ±8dB TREBLE: ±5dB
Sound adjustment: BASS: ±5dB
Microphone: MID: ±5dB TREBLE: ±5dB
Sub Frequency adjustable range: 50Hz-150Hz
Video Input Sensitivity/Impedance: 1vp-p/75Ω
Video Output Sensitivity/Impedance: 1vp-p/75Ω
Power suplly: 220VAC, 50Hz
Power consumption: 10W
Weight(N.W.): 3KG
