Smarter Unit
Based on Pulse Width Modulation (PWM) technology which has been used for over 30 years in power supply and converter, adopt complete digital circuit PWM for high reliability, smaller sizes, less weight
Higher Efficiency
Its efficiency is nearly independent from output level while other common amplifiers can get max efficiency only at biggest output. The overall electric energy convert efficiency is more than 80%.
More Accurate Sound
Crystal clear high frequency, tight and strong low frequency, accurate sound reproduction, professional design ensure great specifications such as distortion, frequency response, convert rate, power supply band width and damping factor. This TC series amplifier adopts higher frequency convert to obtain high resolution of sound signal.
More Comprehensive Protection
This Series amplifier can prevent from and correct every possible fault, can supply powerful output, safely working and long time reliability.
1. Intelligent temperature controlled fans
2. Temperature Protection
3. Short-circuit, Over current Protection
4. Direct Current Protection
5. Over/under- Voltage Protection
Wide Applications in various venues
Together with other C-Mark digital audio products such as digital mixer, network audio platform, to make up digital audio systems suitable for various applications.
Key Specification：
8Ω Rated Output Power（EIAJ THD=1%,1kHz)：4×450w
4Ω Rated Output Power（EIAJ THD=1%,1kHz)： 4×800w
2ΩRated Output Power（EIAJ THD=1%,1kHz)：4×1400w
16ohm Bridged Output Power（EIAJ THD=1%,1kHz)：2×900w
8ohm Bridged Output Power（EIAJ THD=1%,1kHz)：2×1600w
4ohm Bridged Output Power（EIAJ THD=1%,1kHz)：2×2800w
RMS Output Voltage（THD=1%,1kHz)：60V
Upward Slope（1kHz,LP Filter）：50V/us
Input Sensitivity（Rated Power,1kHz)：1Vrms
THD（10% Rated Output Power,Typical）：0.05%
Measurable IMD（10%Rated Output Power, Typical）：0.05%
IMD(10% Rated Output Power,Typical）：0.05%
Crosstalk（1kHz,Typical）：-70dB
Frequency Response(10% Rated Output Power, 8Ω)：0～-2dB
Input Impedance（Balanced）：Balanced 20KΩ, Unbalanced 10KΩ
Damping Factor（100Hz,8Ω)：≥200
S/N（A Weight, 20Hz-20kHz)：≥105dB
Power Supply：AC～100-240V (50-60Hz)
Protection：Overheat Protection、Temperature Power Control、Output Current Control Overload Protection、DC output Protection
Dimension（mm）：483×370×44
Net Weight：8.15Kg
